Description

KEY FEATURES

Advanced Imaging Technology

• Mine Alnu X-ray Generator: Delivers consistent, high-quality radiation output with precise exposure control
• LG Detector Options: Choose between wired for stationary use or wired/wireless for maximum mobility
• High-Resolution Imaging: Produces exceptional image quality with superior detail resolution
• Rapid Image Processing: Near-instantaneous image acquisition and processing capabilities
• High-Capacity Battery: USB-C rechargeable with up to 300 images per charge (5–6 hours charging time).
• Superior Imaging: Works with DR panels and laptops, enhanced by built-in AI for sharper, diagnostic-grade images.
• Safety First: Features a safe-distance sensor, radiation filters for kids/pregnancy, and outdoor-use approval (Korea).
• Versatile Power: Operates at 40–80 kV / 3 mA, suitable for orthopedics, sports medicine, podiatry, and veterinary use.
• Remote Operation: Wireless remote control for 10-meter range, ideal for maintaining safe distances during imaging.

Portability & Convenience

• Lightweight Design: Engineered for easy transport and setup in any environment. At just 2.7 kg, the handheld design and wireless functionality enable effortless use in any setting.
• Aluminum Carrying Case: Professional-grade protection with organized component storage
• Quick Setup: Minimal assembly time for immediate diagnostic readiness
• Battery Operation: Extended wireless operation for field use and emergency situations

Software Excellence

• Intuitive Interface: User-friendly software designed specifically for medical professionals
• Patient Management: Comprehensive patient data organization and retrieval
• Image Enhancement: Advanced post-processing tools for optimal diagnostic clarity

Professional Grade Build

• Durable Construction: Built to withstand the demands of clinical environments
• Regulatory Compliance: Meets all applicable medical device standards and certifications
• Consistent Performance: Reliable operation under various environmental conditions
• Military & Tactical Medicine: Trusted by armed forces for frontline imaging (e.g., Ukrainian Army, NATO missions).
• Global Trust: Used by Ukrainian military, Korean TB programs, and NATO Special Forces (e.g., Greek HYDRA frigate).

TRAINING & SUPPORT

• Comprehensive Training Program

  Our expert training team provides thorough instruction on all aspects of the Nooka X-ray System:

  • On-site Installation Training: Complete system setup and configuration at your facility
  • Hands-on Operation Training: Detailed instruction on system operation and best practices

  d instruction on system operation and best practices

RECOMMENDED USE CASES

• Clinical Applications

  • Emergency Medicine: Rapid trauma assessment and emergency diagnostics
  • Orthopedic Surgery: Intraoperative imaging and post-surgical verification
  • Intensive Care: Bedside imaging for critically ill patients
  • Pediatric Care: Gentle, efficient imaging for young patients
  • Geriatric Medicine: Portable imaging for mobility-limited elderly patients

  Specialized Environments

  • Mobile Clinics: Complete imaging solutions for outreach programs
  • Rural Healthcare: Bringing advanced diagnostics to underserved areas
  • Sports Medicine: On-field injury assessment and athlete care
  • Veterinary Medicine: Portable imaging for animal healthcare facilities
  • Research Facilities: Flexible imaging solutions for clinical studies

  Emergency Situations

  • Disaster Response: Critical imaging capabilities in emergency situations
  • Field Hospitals: Complete diagnostic setup in temporary medical facilities
  • Military Medicine: Portable imaging for combat and field medical operations
  • Ambulatory Care: Enhanced diagnostic capabilities for mobile medical units

TECHNICAL SPECIFICATIONS

• X-ray Generator (Mine Alnu)

  • Weight: 2.7 kg
  • Voltage/Current: 40–80 kV / 3 mA
  • Battery: USB-C, 300 images/charge (5–6 hours charging)
  • Connectivity: Wireless (10-meter remote control range)
  • Safety: Safe-distance sensor, kid/pregnancy filters, outdoor-approved
  • Compatibility: Works with DR panels and laptops
  • AI Integration: Built-in image enhancement

  LG Detector System

  • Detector Type: Amorphous silicon flat panel
  • Active Area: 35 x 43 cm (14″ x 17″)
  • Matrix Size: 2880 x 3408 pixels
  • Pixel Pitch: 139 μm
  • Conversion Method: Indirect conversion (CsI scintillator)
  • Wireless Range: Up to 30 meters (wireless model)
  • Battery Life: 8+ hours continuous operation (wireless model)
  • Image Processing: 14-bit A/D conversion
  • TFT Type: A-Si
  • Scintillator: Csi
  • Number of Pixels: 3072 x 3072
  • Pixel Pitch: 140㎛
  • TFT Dimensions(WxDxH, mm): 445 x 445 mm
  • TFT Active Area(mm): 430.08 × 430.08 mm
  • X-ray sensitive Pixel: 3072 x 3072
  • X-ray sensitive Area(mm): 430.08 x 430.08mm
  • Sensor protection plate: Carbon Fiber Plate
  • Input: DC24V/2.1A
  • Power consumption: Typ. 19.0W (No Charging), 30.5W (with Charging)
  • Weight(kg) / Icld. Battery (Typ.): 3.4kg
  • Maximum Load Weight: Full (Uniform Load) : 300kg Local (Point Load) : 100kg
  • Cycle Time (Ethernet / WLAN): 8sec / 11 sec (Ethernet / WLAN)
  • Full Image (Raw Image) (Typ.): Wired 2 sec / Wireless 2.5 sec (Typ)



  Software System

  • Operating System: Windows 10/11 Professional 64 bit
  • DICOM Compatibility: Full DICOM 3.0 compliance
  • Image Formats: DICOM, JPEG, TIFF, BMP
  • Database: Integrated patient database with backup capabilities
  • Network Connectivity: Ethernet, Wi-Fi, USB connectivity

  Laptop Specifications

  • Processor: Intel Core i5 processor
  • RAM: 16GB DDR4
  • Storage: 0.5 TB SSD
  • Display: 15.6″ Full HD (1920×1080)
  • Graphics: Dedicated graphics card for image processing
  • Connectivity: Multiple USB ports, HDMI output, Ethernet

WHAT’S INCLUDED

• Complete System Package

  • Mine Alnu X-ray Generator: Professional-grade x-ray source with all mounting hardware
  • LG Detector: Choice of wired or wireless detector system with protective housing
  • Laptop Computer: Pre-configured with radiography software and patient management system
  • Aluminum Carrying Case: Custom-fitted protective case with foam inserts
  • Software Suite: Complete imaging software with PACS integration capabilities
  • Cables and Accessories: All necessary connection cables and system accessories

WARRANTY

• 1-year limited warranty for Nooka x-Ray covering manufacturing defects. Extended warranties available for purchase.
• 2-years limited warranty for LG panel covering manufacturing defects.

DELIVERY & AVAILABILITY

• Delivery Time: up to 30 working days.
• Global Availability: FDA-approved (USA), with certifications in Asia, Europe, and the UK.

FAQ

General Questions

Q: Is the Nooka X-ray System suitable for all medical specialties?

A: Yes, the system is designed to support a wide range of medical applications including emergency medicine, orthopedics, internal medicine, and specialized fields requiring portable imaging capabilities.

Q: How long does it take to set up the system?

A: The Nooka X-ray System can be fully operational within 10-15 minutes of unpacking, thanks to its streamlined design and pre- configured components.

Q: What type of training is required to operate the system?

A: We provide comprehensive training programs tailored to your staff’s experience level. Most users become proficient within 2-3 days of hands-on training.

Technical Questions

Q: Can the system integrate with our existing PACS?

A: Yes, the Nooka X-ray System features full DICOM 3.0 compliance and can seamlessly integrate with most existing PACS and HIS systems.

Q: What is the image quality compared to traditional fixed systems?

A: The system delivers image quality comparable to fixed installations, with the added benefits of portability and flexibility.

Q: How long does the wireless detector battery last?

A: The wireless detector provides 2 batteries and 6+ hours of continuous operation on a single charge, with rapid charging capabilities for extended use.

Maintenance and Support

Q: How often does the system require maintenance?

A: Regular preventive maintenance is recommended every 6 months, with our service team providing scheduled maintenance programs.

Q: Is remote technical support available?

A: Yes, we provide 24/7 remote technical support with the capability to diagnose and resolve many issues remotely.

Regulatory and Safety

Q: Does the system meet regulatory requirements?

A: The Nooka X-ray System is fully compliant with FDA regulations and international medical device standards, including CE marking for European markets.

Q: Are there any special facility requirements?

A: The portable nature of the system minimizes facility requirements, though basic radiation safety protocols and appropriate shielding should be maintained according to local regulations.
